Milwaukee Tool

Mouse over image to zoom, click to enlarge

Description: Milwaukee® Corded Rotary Hammer Kit, Reversing, 1-1/8 in Chuck, SDS Max® Chuck, 5500 bpm Blows per Minute, 3.6 ft-lb Impact Energy, 1500 rpm No-Load, 3 Speed, Max Core Bit Compatibility: 4 in, 1-1/8 in Maximum Solid Bit Capacity, 120 V AC, 8 A, Metal/Plastic Housing Material, D-Handle/Drop Motor/Side Handle, Variable Speed Trigger Switch/Forward/Reverse Switch/Clutch Control, Yes Reversible, 12-1/2 in Overall Length

Manufacturer PN: 5268-21

UPC: 04524230366

Kendall Electric Inc PN: 3492018

Invoice Description:

5268-21 MILWAUKE 120V ROTARY HMR KT

▸ See All in Electric Rotary Hammers

How Can We Make This Page Better?

Milwaukee® 5268-21 Reversing Corded Rotary Hammer Kit, 1-1/8 in SDS Max® Chuck, 5500 bpm, 1500 rpm No-Load, 4 in Max Core Bit Compatibility, 1-1/8 in Max Solid Bit Capacity, 12-1/2 in OAL

Note: Lead times are estimates only

Description Specifications Features Resources

Description

Get up to 85% faster drilling and 85% harding hitting while reducing vibration to only 10.6 m/s2. With a powerful 8 amp motor, this rotary hammer delivers 0-1, 500 RPM, 0-5,500 bpm and 3.6 ft-lbs of impact energy. This tool also has an all metal gear case and mechanical clutch to provide maximum durability. At only 12-1/2 in. inches long and 7-1/2 lbs, this tool makes for a very powerful and lightweight 1-1/8 in. 3-mode rotary hammer. The kit includes a side handle, depth rod and carrying case.

Milwaukee® Corded Rotary Hammer Kit, Reversing, 1-1/8 in Chuck, SDS Max® Chuck, 5500 bpm Blows per Minute, 3.6 ft-lb Impact Energy, 1500 rpm No-Load, 3 Speed, Max Core Bit Compatibility: 4 in, 1-1/8 in Maximum Solid Bit Capacity, 120 V AC, 8 A, Metal/Plastic Housing Material, D-Handle/Drop Motor/Side Handle, Variable Speed Trigger Switch/Forward/Reverse Switch/Clutch Control, Yes Reversible, 12-1/2 in Overall Length

Specifications

Amperage Rating	8 A
Blows per Minute	5500 bpm
Brand Name	Milwaukee®
Chuck Size	1-1/8 in
Chuck Type	SDS Max®
Control Type	Variable Speed Trigger Switch/Forward/Reverse Switch/Clutch
Handle Type	D-Handle/Drop Motor/Side
Housing Material	Metal/Plastic
Impact Energy	3.6 ft-lb
Includes	Carrying Case, Depth Rod and Side Handle
Manufacturer Part Number	5268-21
Max Core Bit Compatibility	4 in
Maximum Solid Bit Capacity	1-1/8 in
No Load Speed	1500 rpm
Number of Speeds	3
Overall Length	12-1/2 in
PART NUMBER KEYWORDS	5268-21 ; 526821 ; 13926352 ; 045242303663 ; 45242303663 ; 04524230366 ; 00045242303663
Reversible	Yes
Standards/Approvals	CSA Certified\|ETL Listed\|UL Listed
Tool Kit	Kit
Type	Reversing
Voltage Rating	120 V AC
