Eaton
4731N CWD LKG CONN.2P-3W 15A 125V L5-15R AUTOGRIP CORD.25-.656"

Mouse over image to zoom, click to enlarge

  • 4731N CWD LKG CONN.2P-3W 15A 125V L5-15R AUTOGRIP CORD.25-.656"
  • 4731N CWD LKG CONN.2P-3W 15A 125V L5-15R AUTOGRIP CORD.25-.656"
  • 4731N CWD LKG CONN.2P-3W 15A 125V L5-15R AUTOGRIP CORD.25-.656"

Description: EATON Arrow Hart™ Hart-Lock® AutoGrip™ Eaton Wiring Devices Locking Connector, Grounding Straight, 125 V AC, 15 A, 2 Pole, 3 Wires, NEMA L5-15 NEMA Rating, Industrial/Specification Grade, 0.25 to 0.656 in Diameter Cord, -40 to 75 deg C, Side Wire/Screw Terminal, Phenolic, Black/White, 1.52 in Dia Dimensions

Manufacturer PN: 4731N

UPC:  04089367920

Kendall Electric Inc PN: 19249

Invoice Description:

4731N CWD LKG CONN.2P-3W 15A 125V L5-15R AUTOGRIP CORD.25-.656"


SPEC SHEET

How Can We Make This Page Better?

EATON Arrow Hart™ Hart-Lock® AutoGrip™ Eaton Wiring Devices 4731N Grounding Straight Locking Connector, 125 V AC, 15 A, 2 Poles, 3 Wires, Black/White

Log In for Pricing and Availability




Description

Hart-Lock® industrial specification grade locking devices AutoGrip™ plug and connector 15 A, 125 VAC NEMA L5-15 2-pole 3-wire. Superior design and performance make arrow Hart™ Hart-Lock® devices the ideal choice for industrial applications. Available in a wide range of NEMA and non-Nema configurations.
EATON Arrow Hart™ Hart-Lock® AutoGrip™ Eaton Wiring Devices Locking Connector, Grounding Straight, 125 V AC, 15 A, 2 Pole, 3 Wires, NEMA L5-15 NEMA Rating, Industrial/Specification Grade, 0.25 to 0.656 in Diameter Cord, -40 to 75 deg C, Side Wire/Screw Terminal, Phenolic, Black/White, 1.52 in Dia Dimensions

Specifications

 Amperage Rating 15 A
 Application For locking device applications
 Brand Name EATON
 Color Black/White
 Cord Diameter 0.25 to 0.656 in
 Dimensions 1.52 in Dia
 Grade Industrial/Specification
 Manufacturer Part Number 4731N
 Material Phenolic
 NEMA Rating NEMA L5-15
 Number of Poles 2
 Number of Wires 3
 PART NUMBER KEYWORDS 4731N ; 9593069 ; 040893679204 ; 40893679204 ; 04089367920 ; 00040893679204
 Standards/Approvals CSA certified,cULus Listed,NOM,RoHS Compliant,Federal Specifications Classification W-C375
 Temperature Rating -40 to 75 deg C
 Terminal Type Side Wire/Screw
 Type Grounding Straight
 Video Links
 Voltage Rating 125 V AC

Features

▪ Nylon dead front construction
▪ Back-wire dead front design
▪ Neoprene gasket seals cord hole from dust and debris
▪ Automatic cord grip assembly saves wiring time
▪ Back-wire terminal clamps for easy secure wiring
▪ Individual wiring compartments with tapered channel for easy insertion of wires
▪ Phenolic outer shell/interior body, polycarbonate terminal retainer
▪ Auto grip straight body
▪ 16 to 12 AWG wire

Resources

 Catalog Page
 Product Data Sheet
