Eaton
2NCLPT-2E CH 2.475 MAX KV CLE-PT

Mouse over image to zoom, click to enlarge

Description: EATON Bussmann Current-Limiting Fuse, Medium Voltage Short, Series: NCLPT, Indicating, 2E, 2.5 kV, 40 kA Interrupt, Class: E, Fiberglass Reinforced Resin, 4.5 x 0.81 x 0.81 in Body

Manufacturer PN: 2NCLPT-2E

UPC:  78667021433

Kendall Electric Inc PN: 2018610

Invoice Description:

2NCLPT-2E CH 2.475 MAX KV CLE-PT


SPEC SHEET

▸ See All in Current Limiting Power Fuses


How Can We Make This Page Better?

EATON Bussmann 2NCLPT-2E NCLPT Medium Voltage Short Current-Limiting Fuse, 2E, 2.5 kV, 40 kA Interrupt, Class E

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Our general purpose and full range E-Rated, current-limiting medium voltage fuses are designed for feeder circuit, switchgear and transformer protection. Construction types include ferrule, bolt-on and clip lock, with special application fuses available for use with AMPGARD motor starters.
EATON Bussmann Current-Limiting Fuse, Medium Voltage Short, Series: NCLPT, Indicating, 2E, 2.5 kV, 40 kA Interrupt, Class: E, Fiberglass Reinforced Resin, 4.5 x 0.81 x 0.81 in Body

Specifications

 Amperage Rating 2E
 Application Circuit Protection Applications
 Body Size 4.5 x 0.81 x 0.81 in
 Brand Name EATON
 Class E
 Indicating Non Indicating Indicating
 Manufacturer Part Number 2NCLPT-2E
 Material Fiberglass Reinforced Resin
 Series NCLPT
 Standards/Approvals IEEE Std. C37.41,Not Applicable,Contact Manufacturer
 Type Medium Voltage Short
 Video Links
 Voltage Rating 2.5 kV

Features

▪ Medium voltage fuses are defined by their melting time current characteristic that permit their electrical interchangeability with other fuses of the same E-rating
▪ Physically dimensioned for easy installation in existing hardware and provide designers a space saving size for new installations
▪ Self contained in a non-venting package, PT fuses may be installed indoors or outdoors in an enclosure
▪ Current limiting fuses provide positive interruption even on low fault currents
▪ The fuse limits the magnitude of electromechanical stresses in the protected apparatus
