ABB
  • 2IH4-2 RED 2G RT BOX W/4 3/4 HUBS..
  • 2IH4-2 RED 2G RT BOX W/4 3/4 HUBS..
  • 2IH4-2 RED 2G RT BOX W/4 3/4 HUBS..
  • 2IH4-2 RED 2G RT BOX W/4 3/4 HUBS..

Description: Red Dot® Weatherproof Box, Universal, 4 Outlets, 2 Gangs, 3/4 in Hub, 31.8 cu-in Capacity, Die Cast Aluminum, Powder Coated, Silver, 4-9/16 in L x 4-5/8 in W x 2-1/16 in D Dimensions

Manufacturer PN: 2IH4-2

UPC:  04226939430

Kendall Electric Inc PN: 53909

Invoice Description:

2IH4-2 RED 2G RT BOX W/4 3/4 HUBS..


SPEC SHEET

▸ See All in Weatherproof Device/Outlet Boxes


How Can We Make This Page Better?

Red Dot® 2IH4-2 Universal Weatherproof Box, Die Cast Aluminum, 31.8 cu-in Capacity, 2 Gangs, 4 Outlets, 4-9/16 in L x 4-5/8 in W x 2-1/16 in D

Log In for Pricing and Availability




Description

Preferred for more than 50 years, Red Dot® weatherproof and conduit body solutions withstand the harshest elements and ensure trouble free installation and years of superior performance.
Red Dot® Weatherproof Box, Universal, 4 Outlets, 2 Gangs, 3/4 in Hub, 31.8 cu-in Capacity, Die Cast Aluminum, Powder Coated, Silver, 4-9/16 in L x 4-5/8 in W x 2-1/16 in D Dimensions

Specifications

 Application For Dry-Tite® boxes and covers protect wiring devices, switches, electronic components and terminal blocks in dry, damp and wet locations
 Brand Name Red Dot®
 Color Silver
 Dimensions 4-9/16 in L x 4-5/8 in W x 2-1/16 in D
 Finish Powder Coated
 Hub Size 3/4 in
 Manufacturer Part Number 2IH4-2
 Material Die Cast Aluminum
 Number of Gangs 2
 Number of Outlets 4
 Standards/Approvals UL File No. E286881|Federal Specification UL W-C-586|CSA Certified
 Type Universal

Features

▪ Junction box for branch conduits
▪ Alloy A380 aluminum, certified zinc alloy and stainless steel springs provide increased corrosion-resistance
▪ Die cast construction and industrial design combine to produce a rugged protective enclosure for devices
▪ Clean cover edges provide good gasket sealing
▪ Precision cast and machined surfaces permit safer wire pulling
▪ Clear UL and cubic content markings speed approval by inspectors
▪ Convenient mounting lugs for a variety of mounting methods
▪ Securely fastened mounting plates reduce costly call backs
▪ Dry-tite boxes and covers protect wiring devices, switches, electronic components and terminal blocks in dry, damp and wet locations
▪ Accessible wiring chamber provides a convenient location to maintain or change a system pull conductors and make splices

Resources

 Catalog Page
 Product Data Sheet
