Eaton
277B-BOX CWD SWITCH & P LITE 03266416170

Mouse over image to zoom, click to enlarge

  • 277B-BOX CWD SWITCH & P LITE 03266416170
  • 277B-BOX CWD SWITCH & P LITE 03266416170

Description: EATON Arrow Hart™ Eaton Wiring Devices Combination Toggle Switch, 3-Way Duplex, 120 V AC, 15 A, 1 Pole, Wall Mounting, Screw Terminal, -20 to 60 deg C, Thermoplastic, Brown, 4.19 in H x 1.37 in W x 0.95 in D Dimensions

Manufacturer PN: 277B-BOX

UPC:  03266416170

Kendall Electric Inc PN: 2247410

Invoice Description:

277B-BOX CWD SWITCH & P LITE 03266416170


SPEC SHEET

▸ See All in Switches & Lights


How Can We Make This Page Better?

EATON Arrow Hart™ Eaton Wiring Devices 277B-BOX 3-Way Duplex Combination Toggle Switch With 125 V AC Pilot Light, 120 V AC, 15 A

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

EATON Arrow Hart™ Eaton Wiring Devices Combination Toggle Switch, 3-Way Duplex, 120 V AC, 15 A, 1 Pole, Wall Mounting, Screw Terminal, -20 to 60 deg C, Thermoplastic, Brown, 4.19 in H x 1.37 in W x 0.95 in D Dimensions

Specifications

 Amperage Rating 15 A
 Application Commercial Applications
 Brand Name EATON
 Color Brown
 Dimensions 4.19 in H x 1.37 in W x 0.95 in D
 Manufacturer Part Number 277B-BOX
 Material Thermoplastic
 Mounting Wall
 Number of Poles 1
 PART NUMBER KEYWORDS 277B-BOX ; 277BBOX ; 8166184 ; 032664161704 ; 32664161704 ; 03266416170 ; 00032664161704
 Standards/Approvals cULus Listed,RoHS Compliant
 Temperature Rating -20 to 60 deg C
 Terminal Type Screw
 Type 3-Way Duplex
 Voltage Rating 120 V AC

Features

▪ Thermoplastic top and back body are virtually unbreakable
▪ Mounting straps are zinc plated to for added corrosion-resistance
▪ Heavy duty brass contact
▪ Red lexan pilot lens, neon lamp
▪ Back and Side wire connection
▪ Grounding terminal screw standard
▪ Receptacles have triple wire line contacts and double wipe ground contacts to insure long term plug retention
▪ THK steel mounting strap zinc plated for corrosion-resistance
▪ Break-off provision for wiring both devices on same circuit or on separate circuits
▪ Terminal screws backed out ready for wiring
▪ Side wire terminals accept up to 10 AWG solid or stranded wire
▪ Pilot light may be wired to indicate power On or power Off
▪ Combination slot Phillips® head mounting and terminal screws ease installation

Resources

 Catalog Page
 Product Data Sheet
