Cooper Lighting Solutions
24FP3135C METALUX 2X4 30W 3500K SE 80CRI

Mouse over image to zoom, click to enlarge

  • 24FP3135C METALUX 2X4 30W 3500K SE 80CRI
  • 24FP3135C METALUX 2X4 30W 3500K SE 80CRI
  • 24FP3135C METALUX 2X4 30W 3500K SE 80CRI
  • 24FP3135C METALUX 2X4 30W 3500K SE 80CRI

Description: Metalux LED Panel, Flat, Series: FP Series, 120/277 V, 29.3 W Fixture, 0.25/0.11 A, LED Lighting Technology, 121 Lumens/W Light Output, 60000 hr Average Life, 3500 K Color Temperature, 80 CRI, 0 to 10 V Dimmable Ballast, Clear Acrylic Lens, 3553 Lumens, Insulated Insulation, IP5X Enclosure, Ceiling/Surface/Suspended Mounting, Aluminum Housing Material, 4 ft L x 2 ft W x 2 in H Dimensions

Manufacturer PN: 24FP3135C

UPC:  08008385888

Kendall Electric Inc PN: 4423713

Invoice Description:

24FP3135C METALUX 2X4 30W 3500K SE 80CRI


SPEC SHEET

▸ See All in Indoor Ceiling Fixtures


How Can We Make This Page Better?

Metalux 24FP3135C FP Series Flat LED Panel, 29.3 W Fixture, 120/277 V

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The FPanel LED flat panel series provides premium performance and pleasing aesthetics. The luminaire is optimized for shallow plenum grid ceilings but may also be surface mounted and the 2 x 2 can be suspension mounted. Developed using the latest generation of solid state components and electronic driver technologies, these panels are ideal for both new construction and renovation. The panel's refined visual optics, superior acrylic light guide and integrated grid retention clips provide the features needed for installation, speed and flexibility. The FPanel LED flat panel series is an excellent lighting solution for commercial office spaces, schools, healthcare facilities and retail merchandising areas.
Metalux LED Panel, Flat, Series: FP Series, 120/277 V, 29.3 W Fixture, 0.25/0.11 A, LED Lighting Technology, 121 Lumens/W Light Output, 60000 hr Average Life, 3500 K Color Temperature, 80 CRI, 0 to 10 V Dimmable Ballast, Clear Acrylic Lens, 3553 Lumens, Insulated Insulation, IP5X Enclosure, Ceiling/Surface/Suspended Mounting, Aluminum Housing Material, 4 ft L x 2 ft W x 2 in H Dimensions

Specifications

 Amperage Rating 0.25/0.11 A
 Application Commercial Office, Schools, Healthcare, Retail and Lighting Applications
 Average Life 60000 hr
 Ballast Type 0 to 10 V Dimmable
 Brand Name Metalux
 Color Rendering Index CRI 80
 Color Temperature 3500 K
 Dimensions 4 ft L x 2 ft W x 2 in H
 Enclosure IP5X
 Fixture Wattage 29.3 W
 Housing Material Aluminum
 Includes Wire and Wire Nuts
 Light Output 121 Lumens/W
 Lighting Technology LED
 Lumens 3553 Lumens
 Manufacturer Part Number 24FP3135C
 Mounting Type Ceiling/Surface/Suspended
 PART NUMBER KEYWORDS 24FP3135C ; 16078247 ; 080083858880 ; 80083858880 ; 08008385888 ; 00080083858880
 Series FP Series
 Standards/Approvals California Title 24 Compliant|cULus Listed|DLC Listed|DLC Premium|ECCN: EAR99NLR|IESNA LM-79/80 Compliant
 Type Flat
 Voltage Rating 120/277 V

Features

▪ Ultra-thin less than 2 in height fits shallow plenums with room to spare
▪ Models from less than 20 W and high lumen models up to 7000 lumens
▪ HE models at 136 Lumens/W deliver up to 60% energy savings
▪ Superior optics ensure long life, smooth corner to corner illumination
