Resideo Technologies
9120LBL BRK 120V AC/DC SMOKE ALARM - 10YR LITHIUM BATTERY - LOCKED BATTERY DRAWER ZZZZ

Mouse over image to zoom, click to enlarge

  • 9120LBL BRK 120V AC/DC SMOKE ALARM - 10YR LITHIUM BATTERY - LOCKED BATTERY DRAWER ZZZZ
  • 9120LBL BRK 120V AC/DC SMOKE ALARM - 10YR LITHIUM BATTERY - LOCKED BATTERY DRAWER ZZZZ
  • 9120LBL BRK 120V AC/DC SMOKE ALARM - 10YR LITHIUM BATTERY - LOCKED BATTERY DRAWER ZZZZ
  • 9120LBL BRK 120V AC/DC SMOKE ALARM - 10YR LITHIUM BATTERY - LOCKED BATTERY DRAWER ZZZZ
  • 9120LBL BRK 120V AC/DC SMOKE ALARM - 10YR LITHIUM BATTERY - LOCKED BATTERY DRAWER ZZZZ

Description: BRK® Smoke Alarm, Wire-In, Series: 9120, Dual Ionization Sensor, Alarm: Audio, 18 Units Interconnection, 85 dB Alert, Green/Red LED Indicator Visual Alert, 10 to 90% Humidity, Quick-Connect Wiring, 40 to 100 deg F Operating, Plastic, White, 5.6 in Dia x 2 in H

Manufacturer PN: 9120LBL

UPC:  02905401536

Kendall Electric Inc PN: 3482494

Invoice Description:

9120LBL BRK 120V AC/DC SMOKE ALARM - 10YR LITHIUM BATTERY - LOCKED BATTERY DRAWER ZZZZ


SPEC SHEET

▸ See All in Smoke Detector Alarms


How Can We Make This Page Better?

BRK® 9120LBL Wire-In Smoke Alarm, Dual Ionization Sensor, 85 dB

Log In for Pricing and Availability




Description

The BRK® 9120LBL (model 9120B) is a wire-in, 120 VAC 60 Hz single and/or multiple station smoke alarms specifically designed for residential and institutional applications including sleeping rooms of hospitals, hotels, motels, dormitories and other multi-family dwellings as defined in standard NFPA 101. The 9120LBL complies with UL217, CSFM, NFPA 72, HUD, FHA and other agencies that model their codes after the above agencies. They meet building codes where AC/DC with silence smoke alarms are required. The alarms are interconnectable with up to 18 devices, of which 12 can be smoke alarms.
BRK® Smoke Alarm, Wire-In, Series: 9120, Dual Ionization Sensor, Alarm: Audio, 18 Units Interconnection, 85 dB Alert, Green/Red LED Indicator Visual Alert, 10 to 90% Humidity, Quick-Connect Wiring, 40 to 100 deg F Operating, Plastic, White, 5.6 in Dia x 2 in H

Specifications

 Alarm Type Audio
 Application For single and multiple station alarm specifically designed for residential and institutional applications including sleeping rooms of apartment, hospitals, hotels, motels, dormitories and other multi-family dwellings
 Audible Alert 85 dB
 Brand Name BRK®
 Color White
 Dimensions 5.6 in Dia x 2 in H
 Humidity Rating 10 to 90%
 Includes 9 VDC Lithium Battery Backup
 Interconnection Capability 18 Units
 Manufacturer Part Number 9120LBL
 Material Plastic
 Operating Temperature 40 to 100 deg F
 PART NUMBER KEYWORDS 9120LBL ; ; 029054015365 ; 29054015365 ; 02905401536 ; 00029054015365
 Sensor Type Dual Ionization
 Series 9120
 Standards/Approvals UL 217|CSFM|HUD|FHA|NFPA 101|NFPA 72|ICC Certified
 Type Wire-In
 Visual Alert Green/Red LED Indicator
 Wiring Type Quick-Connect

Features

▪ Locked Battery Drawer
▪ Latching alarm indicator - remembers which unit initiated an alarm
▪ Smart Technology - helps reduce the number of nuisance alarms
▪ Perfect Mount - allows for easy alignment of alarm
▪ Single button test/silence

Resources

 Catalog Page
 Product Data Sheet
