Hubbell
207 RACO 4SQ EXTENSION WELD 2-1/8 DEEP 1/2-3/4 KO

Mouse over image to zoom, click to enlarge

  • 207 RACO 4SQ EXTENSION WELD 2-1/8 DEEP 1/2-3/4 KO
  • 207 RACO 4SQ EXTENSION WELD 2-1/8 DEEP 1/2-3/4 KO
  • 207 RACO 4SQ EXTENSION WELD 2-1/8 DEEP 1/2-3/4 KO
  • 207 RACO 4SQ EXTENSION WELD 2-1/8 DEEP 1/2-3/4 KO

Description: RACO®, 207, Square Box Extension Ring, 12 Knockouts, 1/2 in Knockout, 4 in Length, 4 in Width, 2.19 in Depth, Squared Shape, Knockout Cable Entry, 30.3 cu-in Capacity, Surface Mounting, Steel, Pre-Galvanized, Silver

Manufacturer PN: 207

UPC:  05016900207

Kendall Electric Inc PN: 3833764

Invoice Description:

207 RACO 4SQ EXTENSION WELD 2-1/8 DEEP 1/2-3/4 KO


SPEC SHEET

▸ See All in Square Box Extensions


How Can We Make This Page Better?

RACO® 207 Square Box Extension Ring, 4 in L x 4 in W x 2.19 in D, Steel

Log In for Pricing and Availability




Description

RACO®, 207, Square Box Extension Ring, 12 Knockouts, 1/2 in Knockout, 4 in Length, 4 in Width, 2.19 in Depth, Squared Shape, Knockout Cable Entry, 30.3 cu-in Capacity, Surface Mounting, Steel, Pre-Galvanized, Silver

Specifications

 Application Used to protect electrical wiring, switches, receptacles and to support light fixtures and electrical applications
 Brand Name RACO®
 Cable Entry Size Knockout
 Color Silver
 Depth 2.19 in
 Finish Pre-Galvanized
 Knockout Size 1/2 in
 Length 4 in
 Manufacturer Part Number 207
 Material Steel
 Mounting Type Surface
 Number of Knockouts 12
 PART NUMBER KEYWORDS 207 ; 10992488 ; 11819659 ; 050169002070 ; 50169002070 ; 05016900207 ; 00050169002070 ; 0050169002070
 Shape Squared
 Standards/Approvals UL 514A File No.E195978
 Width 4 in

Features

▪ Combination screw heads allow quick installation
▪ Welded construction
