Description: Schneider Electric TeSys® Thermal Overload Relay, Series: D-Line, 23 to 32 A, 0 to 400 Hz Frequency, 1NO-1NC 1 Form A/1 Form B Contact Form, 10 A Contact, 3 Pole, Contactor/Stand Alone Mounting, Screw Clamp Terminal, IP20 Enclosure, -20 to 60 deg C, 70 mm L x 45 mm W Dimensions

Manufacturer PN: LRD32

UPC:  38911034685

Kendall Electric Inc PN: 4000054

Invoice Description:

LRD32 SQD BIMETALLIC OVERLOAD RELAY


SPEC SHEET

▸ See All in Overload Relays


How Can We Make This Page Better?

Schneider Electric TeSys® LRD32 D-Line Thermal Overload Relay, 23 to 32 A, 1NO-1NC 1 Form A/1 Form B Contact

Log In for Pricing and Availability




Schneider Electric and Square D products are only sold to customers in our authorized sales territory. Please log into your account to see locally available product.

Description

TeSys LRD overload relays are designed to be used with TeSys D contactors to make a motor starter. This overload relay can be used with 9 amp through 38 amp TeSys D contactors. These differential thermal overload relays detect over currents in the lines to the motor. When an overcurrent is detected the overload relay working with the contactor will disconnect the power to the motor. This will minimize the damage to the motor windings. This overload relay has an adjustable trip current rating of 16 to 24 amperes. This trip current rating is calibrated per Class 10A. Multi standards certified (IEC, UL, CSA, CCC, EAC, ATEX, Marine).
Schneider Electric TeSys® Thermal Overload Relay, Series: D-Line, 23 to 32 A, 0 to 400 Hz Frequency, 1NO-1NC 1 Form A/1 Form B Contact Form, 10 A Contact, 3 Pole, Contactor/Stand Alone Mounting, Screw Clamp Terminal, IP20 Enclosure, -20 to 60 deg C, 70 mm L x 45 mm W Dimensions

Specifications

 Amperage Rating 23 to 32 A
 Application For TeSys™ D contactors or standalone applications
 Brand Name Square D
 Contact Form 1NO-1NC 1 Form A/1 Form B
 Contact Rating 10 A
 Dimensions 70 mm L x 45 mm W
 Enclosure IP20
 Frequency Rating 0 to 400 Hz
 Manufacturer Part Number LRD32
 Mounting Type Contactor/Stand Alone
 Number of Poles 3
 PART NUMBER KEYWORDS LRD32 ; 8084278 ; 03389110346855 ; 3389110346855
 Series D-Line
 Standards/Approvals RoHS Compliant|ATEX 94/9|CE Certified|CSA C22 2 No. 14|EN 60947-4-1/60947-5-1|IEC 60947-4-1/60947-5-1|UL 508|PROP65: This product can expose you to chemicals including: Antimony oxide and Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
 Temperature Rating -20 to 60 deg C
 Terminal Type Screw Clamp
 Video Links

Features

▪ Tesys Deca thermal overload relays are designed to protect a.c. circuits and motors against overloads
▪ New modern look and feel of all machines
▪ Easier to install and operate with multi-standard screws
▪ Digital customer experience for technical documents
▪ Maintenance guide via EcoStruxureTM Facility Expert

Resources

 Catalog Page
 Product Data Sheet
