Prysmian
18/3 SJOOW BLACK 250' SPOOL (.305 OD) 300V CORD 01311.15T.01..

Mouse over image to zoom, click to enlarge

  • 18/3 SJOOW BLACK 250' SPOOL (.305 OD) 300V CORD 01311.15T.01..
  • 18/3 SJOOW BLACK 250' SPOOL (.305 OD) 300V CORD 01311.15T.01..

Description: Carol® Carolprene® Portable Cord, Type SJOOW, Reel Packaging, 300 V AC, 10 A, 3 Conductors, Fully Annealed Bare Stranded Copper Conductor, 18 AWG Conductor, 0.305 in OD, 250 ft Length, 16/30 Strands, EPDM Insulation, Carolprene® Rubber Jacket, Black Jacket, 90 deg C

Manufacturer PN: 01311.35T.01

UPC:  07940741225

Kendall Electric Inc PN: 60984

Invoice Description:

18/3 SJOOW BLACK 250' SPOOL (.305 OD) 300V CORD 01311.15T.01..


SPEC SHEET

▸ See All in Portable Cords - SJOOW


How Can We Make This Page Better?

Carol® Carolprene® 01311.35T.01 Type SJOOW Portable Cord, Reel Packaging, 300 V AC, (3) 18 AWG Fully Annealed Bare Stranded Copper Conductor, 250 ft L

Log In for Pricing and Availability




Description

General Cable® Carol® brand plastic cord can be used in a variety of commercial and industrial applications both indoor and outdoor where resistance to oil, chemicals and abrasion is mandatory for powering equipment such as appliances (washers, mixers and lamps), portable tools, lights and motors, hospital, sound and floor maintenance equipment and even in thermostats and other control systems.
Carol® Carolprene® Portable Cord, Type SJOOW, Reel Packaging, 300 V AC, 10 A, 3 Conductors, Fully Annealed Bare Stranded Copper Conductor, 18 AWG Conductor, 0.305 in OD, 250 ft Length, 16/30 Strands, EPDM Insulation, Carolprene® Rubber Jacket, Black Jacket, 90 deg C

Specifications

 Amperage Rating 10 A
 Application Portable Tools and Equipment, Portable Appliances, Small Motors, Associated Machinery, Indoor and Outdoor Applications
 Brand Name Carol®
 Conductor Size 18 AWG
 Conductor Type Fully Annealed Bare Stranded Copper
 Insulation Material EPDM
 Jacket Color Black
 Jacket Material Carolprene® Rubber
 Length 250 ft
 Manufacturer Part Number 01311.35T.01
 Number of Conductors 3
 PART NUMBER KEYWORDS 01311.35T.01 ; 0131135T01 ; 12977217 ; 079407412259 ; 79407412259 ; 07940741225 ; 00079407412259
 Standards/Approvals RoHS Compliant|UL 62|CSA C22.2-49|MSHA Approved
 Strands 16/30
 Temperature Rating 90 deg C
 Type Type SJOOW
 Voltage Rating 300 V AC

Features

▪ Good tensile strength, elongation and aging characteristics
▪ TRU-Mark® sequential footage marking
▪ Premium grade, color coded 90 deg C EPDM insulation
▪ Resist to abrasion, oil, moisture, water, ozone, sunlight (UV) and weather

Resources

 Catalog
 Product Data Sheet
