Leviton
15W47 LEV 15A/125V 2P3W CONN HI-VIS YELLOW 5-15R

Mouse over image to zoom, click to enlarge

Description: Leviton®, 15W47, Straight Blade Connector, 1-Phase Cable Mount Grounding Watertight, 125 V AC, 15 A, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Industrial Grade, NEMA 4/4X/12/IP66/IP67 Enclosure, 0.234 to 0.687 in Diameter Cord, -40 to 60 deg C, Screw Terminal, TPV, Yellow, 1.78 in Dia x 4.22 in L Dimensions

Manufacturer PN: 15W47

UPC:  07847784824

Kendall Electric Inc PN: 42158

Invoice Description:

15W47 LEV 15A/125V 2P3W CONN HI-VIS YELLOW 5-15R


SPEC SHEET

▸ See All in Straight Blade Connectors


How Can We Make This Page Better?

Leviton® 15W47 1-Phase Cable Mount Grounding Watertight Straight Blade Connector, 125 V AC, 15 A, 2 Poles, 3 Wires, Yellow

Log In for Pricing and Availability




Description

Leviton® Wetguard® line of industrial watertight wiring devices are the most versatile, well engineered watertight devices ON the market. They meet IP67 and NEMA ratings for water ingress protection and offer many significant advantages over competitive brands.
Leviton®, 15W47, Straight Blade Connector, 1-Phase Cable Mount Grounding Watertight, 125 V AC, 15 A, 2 Pole, 3 Wires, NEMA 5-15R NEMA Rating, Industrial Grade, NEMA 4/4X/12/IP66/IP67 Enclosure, 0.234 to 0.687 in Diameter Cord, -40 to 60 deg C, Screw Terminal, TPV, Yellow, 1.78 in Dia x 4.22 in L Dimensions

Specifications

 Amperage Rating 15 A
 Brand Name Leviton®
 Color Yellow
 Cord Diameter 0.234 to 0.687 in
 Dimensions 1.78 in Dia x 4.22 in L
 Enclosure NEMA 4/4X/12/IP66/IP67
 Grade Industrial
 Manufacturer Part Number 15W47
 Material TPV
 NEMA Rating NEMA 5-15R
 Number of Poles 2
 Number of Wires 3
 PART NUMBER KEYWORDS 15W47 ; 7344504 ; 15W47 ; 078477848241 ; 78477848241 ; 07847784824 ; 00078477848241
 Standards/Approvals ANSI C-73|NOM 057|NEMA WD-1/WD-6|UL 498|CSA C22.2 No. 42|UL94 V-2 Flammability Rating
 Temperature Rating -40 to 60 deg C
 Terminal Type Screw
 Type 1-Phase Cable Mount Grounding Watertight
 Video Links
 Voltage Rating 125 V AC

Features

▪ Corrosion resistant electroless nickel coated brass blades, contacts, terminal screws and wiring clamps and stainless steel assembly screws make these devices ideal for use in wet and corrosive environments
▪ EPTR rubber part provides outstanding resistance to wet and damp environments, extreme temperature variations, water, acids, alkalis, grease, oils and many automotive and industrial lubricants and solvents
▪ Plug and connector husk is molded to a bondable nylon body, providing a device that withstands physical abuse
▪ Interlocking tongue and groove construction seals out water, moisture and dirt when plugs are mated with connectors
▪ Multi-point sealing system utilizes nut, strain relief washer and rubber bushing to form a watertight cord grip seal
▪ Non-magnetic stainless steel fast threading assembly screws wont interfere with sensitive equipment
▪ Connector hood closure cap seals device when not in use
▪ 18 to 10 AWG terminal accommodation
▪ S/ST/SO/SOW cord
