Prysmian
14/4 SJOOW BLACK 250'REEL (.415 OD) 300V CORD

Mouse over image to zoom, click to enlarge

  • 14/4 SJOOW BLACK 250'REEL (.415 OD) 300V CORD
  • 14/4 SJOOW BLACK 250'REEL (.415 OD) 300V CORD

Description: Carol® Portable Cord, Type SJOOW, Reel Packaging, 300 V AC, 15 A, 4 Conductors, Fully Annealed Bare Stranded Copper Conductor, 14 AWG Conductor, 0.41 in OD, 250 ft Length, 41/30 Strands, EPDM Insulation, Carolprene® Jacket, Black Jacket, -40 to 90 deg C

Manufacturer PN: 01364.35T.01

UPC:  07940741207

Kendall Electric Inc PN: 60975

Invoice Description:

14/4 SJOOW BLACK 250'REEL (.415 OD) 300V CORD


SPEC SHEET

▸ See All in Portable Cords - SJOOW


How Can We Make This Page Better?

Carol® 01364.35T.01 Type SJOOW Portable Cord, Reel Packaging, 300 V AC, (4) 14 AWG Fully Annealed Bare Stranded Copper Conductor, 250 ft L

Log In for Pricing and Availability




Description

General Cable® Carol® brand plastic cord can be used in a variety of commercial and industrial applications both indoor and outdoor where resistance to oil, chemicals and abrasion is mandatory for powering equipment such as appliances (washers, mixers and lamps), portable tools, lights and motors, hospital, sound and floor maintenance equipment and even in thermostats and other control systems.
Carol® Portable Cord, Type SJOOW, Reel Packaging, 300 V AC, 15 A, 4 Conductors, Fully Annealed Bare Stranded Copper Conductor, 14 AWG Conductor, 0.41 in OD, 250 ft Length, 41/30 Strands, EPDM Insulation, Carolprene® Jacket, Black Jacket, -40 to 90 deg C

Specifications

 Amperage Rating 15 A
 Application Portable Tools and Equipment, Portable Appliances, Small Motors and Associated Machinery, Indoor and Outdoor Applications
 Brand Name Carol®
 Conductor Size 14 AWG
 Conductor Type Fully Annealed Bare Stranded Copper
 Insulation Material EPDM
 Jacket Color Black
 Jacket Material Carolprene®
 Length 250 ft
 Manufacturer Part Number 01364.35T.01
 Number of Conductors 4
 PART NUMBER KEYWORDS 01364.35T.01 ; 0136435T01 ; 12977212 ; 079407412075 ; 79407412075 ; 07940741207 ; 00079407412075
 Standards/Approvals RoHS Compliant|UL 62|CSA C22.2-49|MSHA Approved
 Strands 41/30
 Temperature Rating -40 to 90 deg C
 Type Type SJOOW
 Voltage Rating 300 V AC

Features

▪ Good tensile strength, elongation and aging characteristics
▪ TRU-Mark® sequential footage marking
▪ Premium grade, color coded 90 deg C EPDM insulation
▪ Resist to abrasion, oil, moisture, water, ozone, sunlight (UV) and weather

Resources

 Catalog
 Product Data Sheet
