Eaton
12155RD10 CH PRISM 20 FT R/A SYNCHRONOUS DETECTOR AC&DC CABLE DARK OP

Mouse over image to zoom, click to enlarge

  • 12155RD10 CH PRISM 20 FT R/A SYNCHRONOUS DETECTOR AC&DC CABLE DARK OP
  • 12155RD10 CH PRISM 20 FT R/A SYNCHRONOUS DETECTOR AC&DC CABLE DARK OP

Description: EATON Prism® Photoelectric Sensor, Forward Viewing, Tubular Shape, Thru-Beam Sensing Method, 20 ft Sensing, Visible Red Sensing Beam, 3 ms Response, 20 to 132 VAC, 15 to 30 VDC, 80/110 mA, 2 W Wattage, 50/60 Hz Frequency, 6.6 ft Cable Connection, Red Output Status LED Indicator Light Source, 30 g Vibration, 0.47 in L x 0.71 in W x 2.55 in H Size, NEMA 1/3/4/4X/6/6P/12/13 Enclosure, -13 to 131 deg F Operating, Surface Mounting

Manufacturer PN: 12155RD10

UPC:  78211305659

Kendall Electric Inc PN: 4797111

Invoice Description:

12155RD10 CH PRISM 20 FT R/A SYNCHRONOUS DETECTOR AC&DC CABLE DARK OP


SPEC SHEET

▸ See All in Thru-Beam, Tubular Style Receiver


How Can We Make This Page Better?

EATON Prism® 12155RD10 Forward Viewing Photoelectric Sensor, Tubular Shape, 20 ft, Visible Red Sensing Beam, 3 ms Response

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Prism series 18 mm tubular sensors provide a flexible isolated output and twice the optical gain of other sensors in this product class. These cost-effective sensors offer forward- and right-angle viewing models that feature identical gain and optical characteristics for the best fit.
EATON Prism® Photoelectric Sensor, Forward Viewing, Tubular Shape, Thru-Beam Sensing Method, 20 ft Sensing, Visible Red Sensing Beam, 3 ms Response, 20 to 132 VAC, 15 to 30 VDC, 80/110 mA, 2 W Wattage, 50/60 Hz Frequency, 6.6 ft Cable Connection, Red Output Status LED Indicator Light Source, 30 g Vibration, 0.47 in L x 0.71 in W x 2.55 in H Size, NEMA 1/3/4/4X/6/6P/12/13 Enclosure, -13 to 131 deg F Operating, Surface Mounting

Specifications

 Amperage Rating 80/110 mA
 Application Automation and Logic Control Equipment, Vehicles On-Road PickUp and Delivery Food Applications
 Brand Name EATON
 Connection Type 6.6 ft Cable
 Enclosure NEMA 1/3/4/4X/6/6P/12/13
 Frequency Rating 50/60 Hz
 Manufacturer Part Number 12155RD10
 Mounting Type Surface
 Operating Temperature -13 to 131 deg F
 Response Time 3 ms
 Sensing Beam Visible Red
 Sensing Method Thru-Beam
 Sensing Range 20 ft
 Shape Tubular
 Size 0.47 in L x 0.71 in W x 2.55 in H
 Standards/Approvals cUL Recognized,UL Recognized,CE Marked
 Type Forward Viewing
 Vibration 30 g
 Voltage Rating 20 to 132 V AC/15 to 30 V DC
 Wattage 2 W

Features

▪ Quick 3 ms response time on all models
▪ Highly visible output status LED
▪ Custom cable length options
▪ Polycarbonate cable lens, PVC jacket, structural polyurethane foam body enclosure material
▪ Current limited for loads less than 32 VAC/VDC
▪ Isolated solid state relay contact configuration
▪ Right angle viewing models mount in a depth of only 6/10th of an inch
▪ Small size for use in a wide variety of applications and locations
▪ High sensing power for longer ranges and resistance to dust and dirt
▪ Adjustable gain control to ensure peak optical performance
▪ High noise immunity which greatly reduces problems associated with electrical noise
▪ DC only models which offer lower cost options in all sensing modes
▪ Isolated outputs for wiring flexibility
▪ Short circuit protection is provided by an adjustable instantaneous only
▪ Built-in cable models allow for lowest cost wiring
▪ Micro-connector models provide for quick installation or replacement
