Eaton
10250TS39 CH LGD PLT SQ HAND AUTO

Mouse over image to zoom, click to enlarge

Description: EATON Legend Plate, 2-Position Standard, Series: 10250T, Square Plate Shape, Selector Switch/Roto-Push Operator, HAND AUTO Legend, White Legend, 0.1 in Height, 1.7 in Width, Black Field

Manufacturer PN: 10250TS39

UPC:  78211336058

Kendall Electric Inc PN: 2150114

Invoice Description:

10250TS39 CH LGD PLT SQ HAND AUTO


SPEC SHEET

How Can We Make This Page Better?

EATON 10250TS39 10250T 2-Position Standard Legend Plate, 0.1 in H x 1.7 in W, Square Plate, Black Field

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Eaton's 10250T line of 30.5 mm pushbuttons features a heavy-duty zinc die cast construction. Reliability nibs improve contact reliability even under dry circuit and fine dust conditions. In addition, drainage holes prevent the buildup of liquid inside the operator, which can prevent operation in freezing environments.
EATON Legend Plate, 2-Position Standard, Series: 10250T, Square Plate Shape, Selector Switch/Roto-Push Operator, HAND AUTO Legend, White Legend, 0.1 in Height, 1.7 in Width, Black Field

Specifications

 Application For use with 10250T Series selector switch and roto push operators and automation and logic control equipment applications
 Brand Name EATON
 Field Color Black
 Height 0.1 in
 Legend HAND AUTO
 Legend Color White
 Manufacturer Part Number 10250TS39
 PART NUMBER KEYWORDS 10250TS39 ; 7316856 ; 782113360584 ; 78211336058 ; 00782113360584
 Plate Shape Square
 Series 10250T
 Standards/Approvals CSA Certified,UL Listed,CE Marked
 Type 2-Position Standard
 Video Links
 Width 1.7 in

Features

▪ EATON's contact blocks feature enclosed silver contacts with pointed reliability nibs
▪ To ensure reliable switching, these nibs bite through oxide, which can form on silver contacts, eliminating the need for expensive logic level blocks for most applications
▪ 1.7 in L
▪ Has a satin aluminum field, color is on lower portion
▪ 5/32 in H letter

Resources

 Catalog Page
 Product Data Sheet
