Eaton
10250T181LGP06 CH IND LIGHT XFR 120VAC GREEN LED - PLASTIC LENS

Mouse over image to zoom, click to enlarge

  • 10250T181LGP06 CH IND LIGHT XFR 120VAC GREEN LED - PLASTIC LENS
  • 10250T181LGP06 CH IND LIGHT XFR 120VAC GREEN LED - PLASTIC LENS
  • 10250T181LGP06 CH IND LIGHT XFR 120VAC GREEN LED - PLASTIC LENS
  • 10250T181LGP06 CH IND LIGHT XFR 120VAC GREEN LED - PLASTIC LENS

Description: EATON Indicating Light, Heavy Duty Oiltight Watertight Standard Actuator, Series: 10250T, 120 V AC, 0.5 A, Fresnel Lens, Green Lens, Plastic Lens, LED Lamp, Bezel/Housing: Polished Chrome, 30.5 mm, Round, Bayonet Base, 60000 to 100000 hr Average Life, Pressure Plate Terminal, NEMA 3/3R/4/4X/12/13/IP65, Panel Mount, Environmental Conditions: 1 to 150 deg F Operating, 95% Relative Humidity at 60 deg C

Manufacturer PN: 10250T181LGP06

UPC:  78211471137

Kendall Electric Inc PN: 3642312

Invoice Description:

10250T181LGP06 CH IND LIGHT XFR 120VAC GREEN LED - PLASTIC LENS


SPEC SHEET

▸ See All in Pilot Light Operators


How Can We Make This Page Better?

EATON 10250T181LGP06 10250T Heavy Duty Oiltight Watertight Standard Actuator Indicating Light, 120 V AC, 0.5 A, Fresnel Lens, Panel Mount

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Eaton's 10250T line of 30.5 mm pushbuttons features a heavy-duty zinc die cast construction. Reliability nibs improve contact reliability even under dry circuit and fine dust conditions. In addition, drainage holes prevent the buildup of liquid inside the operator, which can prevent operation in freezing environments.
EATON Indicating Light, Heavy Duty Oiltight Watertight Standard Actuator, Series: 10250T, 120 V AC, 0.5 A, Fresnel Lens, Green Lens, Plastic Lens, LED Lamp, Bezel/Housing: Polished Chrome, 30.5 mm, Round, Bayonet Base, 60000 to 100000 hr Average Life, Pressure Plate Terminal, NEMA 3/3R/4/4X/12/13/IP65, Panel Mount, Environmental Conditions: 1 to 150 deg F Operating, 95% Relative Humidity at 60 deg C

Specifications

 Amperage Rating 0.5 A
 Application Automation and Logic Control Equipment Applications
 Average Life 60000 to 100000 hr
 Base Bayonet
 Bezel Housing Polished Chrome
 Brand Name EATON
 Enclosure NEMA 3/3R/4/4X/12/13/IP65
 Environmental Conditions 1 to 150 deg F Operating, 95% Relative Humidity at 60 deg C
 Lamp Type LED
 Lens Color Green
 Lens Material Plastic
 Manufacturer Part Number 10250T181LGP06
 Mounting Type Panel
 PART NUMBER KEYWORDS 10250T181LGP06 ; 7407247 ; 782114711378 ; 78211471137 ; 00782114711378
 Series 10250T
 Shape Round
 Size 30.5 mm
 Standards/Approvals CSA Certified,UL Listed,CE Marked
 Terminal Type Pressure Plate
 Type Heavy Duty Oiltight Watertight Standard Actuator
 Video Links
 Voltage Rating 120 V AC

Features

▪ Transformer type light unit
▪ 2.4 in L x 2.1 in W x 3.2 in H dimension
