Electri-Flex Company
1/2" LAFG-11 LIQUID-TIGHT CONDUIT 21901 MOQ 100FTBOX

Mouse over image to zoom, click to enlarge

Description: Electri-Flex Liquatite® Liquid Tight Flexible Conduit, Type LAFG-11, 1/2 in Trade, 0.622 to 0.642 in ID, 0.82 to 0.84 in OD, 25/100 ft Carton Length, 3 in Bend Radius, -30 to 105 deg C, Steel, Blue, Hot Dipped Galvanized

Manufacturer PN: LAFG-11

UPC:  78267321901

Kendall Electric Inc PN: 3359381

Invoice Description:

1/2" LAFG-11 LIQUID-TIGHT CONDUIT 21901 MOQ 100FTBOX


SPEC SHEET

▸ See All in Liquidtight Flexible Metal Conduit(LFMC)


How Can We Make This Page Better?

Electri-Flex Liquatite® 21901 Type LAFG-11 Liquid Tight Flexible Conduit, 1/2 in Trade, 0.622 to 0.642 in ID x 0.82 to 0.84 in OD, 25/100 ft Carton L, Steel

Log In for Pricing and Availability




Description

A UL Listed, flexible liquidtight steel conduit that is antimicrobial and is designed for a variety of installations regarding motion, vibration, and bending on food processing equipment. Inner core construction consists of hot dipped galvanized steel, 3/8" - 1-1/4" squarelock profile with continuous bonding strip, and 1-1/2" - 4" fully interlocked profile. The jacket is formulated for "splash zone" food and beverage contact, resistant to sodium hypochlorite (bleach), flame retardant, sunlight (UV) resistant, and resistant to oils and mild acids.
Electri-Flex Liquatite® Liquid Tight Flexible Conduit, Type LAFG-11, 1/2 in Trade, 0.622 to 0.642 in ID, 0.82 to 0.84 in OD, 25/100 ft Carton Length, 3 in Bend Radius, -30 to 105 deg C, Steel, Blue, Hot Dipped Galvanized

Specifications

 Application Food Processing, Healthcare and Pharmaceuticals Applications
 Bend Radius 3 in
 Brand Name Electri-Flex
 Color Blue
 Finish Hot Dipped Galvanized
 Inside Diameter 0.622 to 0.642 in
 Length 25/100 ft Carton
 Manufacturer Part Number 21901
 Material Steel
 PART NUMBER KEYWORDS 21901 ; 782673219018 ; 78267321901 ; 00782673219018
 Standards/Approvals ARRA Compliant|BS EN IEC File No. 61386|CE Certified|FDA CFR21|NSF 51/61|RoHS Compliant|WEEE Compliant
 Temperature Rating -30 to 105 deg C
 Trade Size 1/2 in
 Type Type LAFG-11
 Video Links

Features

▪ Formulated for splash zone food and beverage contact
▪ Resistant to oils and mild acids
▪ Flame retardant

Resources

 Product Data Sheet
 RoHS
